현상 : MDI 자식폼에서 팝업창을 모달리스로 띄울 경우 불특정 상황에서(파악안됨
--;;)
팝업된 창이 메인 창 뒤로 숨겨져 버림 ㅡ,.ㅜ
MDI 인 경우인지 메인폼에 타이머(타이머 없애도 안되더라...)가 있어서 인지는
모르겠으나
API 로 해도 해결이 안되었음
결국,
별도스레드로 팝업하게 변경 후 해결
아래소스는 CodeProject 에서
검색된것.. 후킹에 관한 좋은 샘플도 되고하니..
일단 펌.. ^^
Introduction
In .NET,
there are a few functions for working with windows (of other
applications). The most part have appeared in .NET 3.0, but they
are not enough. So, we have to use the WinAPI functions.
I introduce here the CWindow class, which is the
wrapper class for the required window API functions.
About
I decided to make CWindow look like the System.Windows.Forms.Form .NET class. So, the description of the majority of
the functions/properties is similar to the functions/properties with the same
name from the Form class. Sometimes, even the inner
construction is the same.
In this article, I wouldn’t describe
all the functions/properties, but just those that differ enough from the
same of the Form .NET class. The description for
others can be obtained from the CWindow code or
from MSDN. The code is commented well enough, and most of
the descriptions in this article are just short descriptions of the
functions in the class code with the explanations. I decided not
to throw exceptions in CWindow at all, because mistakes
could be very specific, and it is better to catch them
in the main code.
The IuSpy program was written first
as just an example of using the CWindow class.
But then, after getting a working application, I decided to decorate
it and make it comfortable for usage. So remember, IuSpy is
not the end product. You can see how some CWindow
functions/properties work, but don't be sure that it is the
best way. For example, in TreeForm and FindWindowForm
, I enumerate all windows, but in TreeForm, I
did it in a slower fashion. It is just an example.
IuSpy is a very simple program. Almost all controls have tooltips.
That’s why I wouldn’t describe it in this article. You can
see its picture in the top of this page.
CWindow
Class
Static Functions/Properties
Properties
TopWindow - Gets/sets the window at the top of the window's Z
order.StateChangeAnimation - Gets/sets whether windows animation, when
minimizing and maximizing, is enabled.ActiveWindow - Gets/sets
the currently active window.FocusedWindow - Gets/sets the
window that has the keyboard focus.Captured -
Gets the window (if any) that has captured the mouse.DesktopWindow - Gets the desktop window.
Functions
FromPoint - Retrieves the window at a
specified location.FindWindow - Overloaded. Retrieves a window
whose class name and window name match the specified values.EnumWindows - Enumerates all top-level windows on the screen.
For details, see EnumWindows in MSDN, or the description
in the code.EnumThreadWindows - Enumerates all non-child
windows associated with the specified thread. For details, see EnumThreadWindows
in MSDN, or the description in the code.GetThreadWindows - Retrieves the collection of top-level windows contained within
the specified thread.
Object of a Class
The
CWindow object is just an IntPtr – a handle to a window.
Implicit Operators
CWindow -> IntPtr; IntPtr -> CWindow; CWindow ->
int;
Overloaded Operators
==/!= (
CWindow, CWindow), ==/!= (CWindow, IntPtr). So you can use this in such a
way:
Collapse
Copy CodeIntPtr p;
CWindow w,w2;
w = new CWindow(p);
w = p;
p = w;
w = 0x15864;
if(w == w2)…
if(w != p)…
Window Info
TextUnsafe - Gets/sets the text associated with this window. The simple Text property can’t get/set the text of most window types.
TextUnsafe sends a message to the specified window, so
your application can hang if that window is not responding. Check
IsHung before using this property.Exists - Determines whether this object identifies an existing window.Menu - Gets/sets a handle to the menu assigned to
the window.ThreadId - Gets the identifier of
the thread that created this window.ProcessId -
Gets the identifier of the process that created the window.IsUnicodeWindow - Determines whether the specified window is a
native Unicode window.IsHung - Determines if Microsoft
Windows considers that a specified application is not responding.ClassName - Gets the name of the class to which
the specified window belongs to.RealClassName - Gets
a string that specifies the window type.
You can
get icons with the following properties:
IconSmallIconClassIconSmallClassIcon
Be careful with these properties, check IsHung
first. If you want to set your icon, you need
to write it to the memory space of the process to
which the window belongs to. You can do this with WriteProcessMemory(). But don't forget, that you also need to destroy
the old icon. You have to call DestroyIcon() from
the space of the window's process. For these operations, you have
to inject your Win32 DLL with the help of hooks. I
use some of my other classes for this, and I decided
not to put them all together.
Styles
StylesUpdateStyles()GetStyle()SetStyle()
You can get window styles
with the help of GetStyle() and set them with
SetStyle(). If you need to get or set styles
several times for the same window, you can use the Styles property and an object of the WindowStyle class returned by it. Don’t forget that you not only need
to set the styles to a window, but also apply them.
You can do this with UpdateStyles(), or specify this
in the SetStyle() function.
Extended Styles
ExStylesUpdateExStyles()GetExStyle()SetExStyle()
Description is the same as
for the simple styles.
State
Properties
WindowState - Gets/sets the window's state.WindowVisibleState - Gets/sets the window's visible state. Implemented the same as Form.WindowState. Sometimes it differs from the real window state. For
changing the real current state, use WindowState.RestoreToMaximized - Gets/sets a value indicating whether the window is
maximized in the restored state.
Functions
Minimize - Minimizes the window.Restore -
Restores the window from minimized to its previous state.
Window Relations
Properties
Children - Gets
the collection of windows contained within the window. It contains only
the immediate child windows.IsTopWindow - If the
current window is a top-level window, checks if it is at
the top of the Z order. If the window is a
child window, checks if it is at the top of its
parent's Z order.ThreadWindows - Gets the collection
of the top-level windows contained within the window's thread.TopChild - Gets the child window at the top of
the Z order, if this window is a parent window; otherwise,
returns null-window.TopLevelWindow - Retrieves the root window
by walking the chain of parent windows.
Functions
EnumChildWindows - Enumerates the child windows that belong
to this window.EnumThreadWindows - Enumerates all non-child
windows associated with the current thread.FindChildWindow -
Overloaded. Retrieves the window whose class name and window name match
the specified values.GetNextWindow - Retrieves a window that has the specified relationship (Z-Order or owner) to this window.InsertAfter -
Inserts this window after the specified window in the Z order.
Other
Transparent - Gets/sets whether
the window is considered to be transparent. Can be used for
hit testing or for drawing under-layered windows.ForceActivate() - Activates the window and gives it focus. The Activate()
function can’t activate the window in some cases, for example,
when a popup window is shown. So you can use the
ForceActivate() function, if you want to activate a window
in any case.
Namesakes
The description of the
following properties/function can be seen in the class code or in
MSDN. Remember that their real descriptions may not fully repeat the
MSDN description. So, with the MSDN description you can decide whether
it is the function that you need, and then see the
specification in the class code.
WindowRelations
HasChildren
OwnerParentTopLevel
BringToFront()Contains()
GetChildAtPoint()SendToBack()SetTopLevel()
Coordinates
BottomBoundsClientRectangleClientSizeDesktopBoundsDesktopLocationHeight
LeftLocationMaximizedBoundsMaximumSizeMinimumSizeRestoreBoundsRightSizeTopWidthPointToClient()
PointToScreen()RectangleToClient()RectangleToScreen()
Visibility
AllowTransparency
OpacityRegionTransparencyKeyVisible
Hide()
Invalidate()Refresh()Show()Update()
Window Info
HandleTextEnabled
ModalCanFocusFocusedContainsFocus
Others
Activate()Close()CreateGraphics()Focus()
Additional Classes
CWindowWorker, CWindowsWorker
These classes were not made big. They contain only basic features,
with the help of which you can try to implement everything
that you need.
CWindowWorker
You can use the CWindowWorker class if you want to change several properties of
a window in a single screen-refreshing cycle. The constructor is simple.
Just put there the CWindow object or a handle
to a window. With this class, you can change the Location, Size, and Visible state of
the window, set styles and extended styles, and also set the
window order.
You can set the window styles with SetStyle() or SetExStyle(), but they will be applied
to a window when you call the Reposition() function.
The overloaded SetOrder() changes the window’s placement in
the Z-order. But, remember that you can use this function only
once for the current reposition. This is the only function in
the Iu.Windows namespace where I throw an exception if
this function is called more than once for the current object,
because that is an obvious developer mistake.
Call RePosition()
at the end to apply everything that you have specified.
CWindowsWorker
Use this class when you want to change
properties of several windows in a single screen-refreshing cycle. This class
has only the indexer and the Reposition() function.
You can specify a CWindow object or a handle
in the indexer, and you will get an object of the
CWindowWorker class for a specified window. You can specify
everything that you want in the returned object, but don’t call
Reposition().
At the end, after changing all the
windows, call the Reposition() function of the CWindowsWorker
class to apply all the changes.
WindowStyle, WindowExStyle
The Styles and ExStyles properties of the
CWindow class returns objects of the aforesaid classes. They
were written to check/set the specified styles. They are useful when
you need to check/set styles several times for the same window.
Both of these classes have the Check() and Set() functions and a lot of implicit operators.
aboutbox_demo-net2-csharp.zip
